Title: [Erie Canal (New York) Lock. Plan, sections, and elevation] / drawn under the direction of D.H. Mahan, Profr. of Engineering ; by Orlando M. Poe, U.S. Corps Cadets.
Creator(s): Poe, O. M. (Orlando Metcalfe), 1832-1895, delineator
Related Names:
Mahan, D. H. (Dennis Hart), 1802-1871 , engineer
Date Created/Published: [between 1852 and 1856]
Notes:
Inscription: 'Erie Canal. Plan, sections, and elevation of a canal lock.'
Drawn as an exercise while a student at U.S. Military Academy, West Point, N.Y.
Illegible signature in lower right corner.
Scaled.
Exhibited: American Treasures of the Library of Congress, 2003-2004.
Subjects:
Canals--New York (State)--1850-1860.
Locks (Hydraulic engineering)--New York (State)--1850-1860.
Erie Canal (N.Y.)--1850-1860.
Drawings--1850-1860.
Engineering drawings--1850-1860.
Student works--1850-1860.
